ACT01 Web Guiding Actuator

ACT01 is a servo actuator for web guiding systems, used as the final correction mechanism to move the guiding frame according to controller commands. It features absolute position feedback, small backlash, electronic limit control and maintenance-friendly operation.

Request Quotation

Key Features

Servo actuator with absolute position feedback for web guiding correction.

Three-phase servo motor design supports high torque, brushless operation and reduced maintenance.
Ball screw transmission helps reduce backlash and supports stable correction movement.
Absolute position feedback allows real-time monitoring of actuator travel.
Electronic limit control reduces the need for mechanical return or limit switches.
Auto-centering function can return the actuator to center when no material is detected.
Flexible installation for different web guiding frame layouts.

Product Type	Servo actuator for web guiding systems
Source / Brand	Pausource
ACT01-80	Maximum speed: 40 mm/s; drive stroke: ±40 mm
ACT01-100	Maximum speed: 50 mm/s; drive stroke: ±50 mm
ACT01-180	Maximum speed: 50 mm/s; drive stroke: ±90 mm
Maximum Thrust	1000 N or 2500 N
Working Voltage	24 V DC
Ambient Temperature	−10°C to +80°C
Air Humidity	0–90% RH, non-condensing
Protection Class	IP54
Shell Material	45# steel
Rated Power	150 W

Selection Notes

Choose ACT01 when servo actuator control, absolute position feedback and stable correction movement are required.

Good Fit

Standard correction structures requiring servo control, position feedback and flexible installation.

Check First

For heavier correction load or larger frame structures, ACT03 or WU10000 may be more suitable.

System Match

Use with a compatible web guiding controller, sensor and correction frame selected according to web width, correction load, stroke and installation space.
