Electrostatic spraying
Catalog-listed application area for this static control product family.
Static Generation
Static Generation Products
Static generation products create controlled electrostatic charge for applications that require temporary attraction, holding, positioning or process support.
Technical Parameter
Catalog parameters for Static Generation Products.
The catalog static generation section includes YP-HV03, YP-HV05, YP-HV05-4, YP-HV-BF generator rods and YP-HV05-X4 smart high-voltage power supply products.
| Catalog Products | YP-HV03 Series; YP-HV05 Series; YP-HV05-4 Series; YP-HV-BF10/BF20/BF21/BF22 Electrostatic Generator Rods; YP-HV05-X4 Smart Model |
|---|---|
| Output Voltage | Continuously adjustable high-voltage output, listed by model |
| Output Current | Continuously adjustable and listed by model |
| Working Distance | Listed for generator rod models |
| Working Mode | Listed by model in the catalog technical parameter tables |
| Cable | Listed for generator rod models |
| Output Display | Digital voltage and current display; LCD on smart model |
| Protection | Short circuit, overvoltage, overcurrent, arc pulling and output short-circuit protection |
| Control Mode | Local control and remote control on smart model |
Product Features
Features shown in the static control catalog.
- YP-HV high-voltage electrostatic generator is used for electrostatic spraying, electrostatic suction and electrostatic dust removal fields.
- Output voltage and current are continuously adjustable, with digital display on generator products.
- Catalog describes modular design, small time drift and temperature drift, high stability, overload and short-circuit protection.
- Smart high-voltage power supply includes voltage/current display, protection functions and controllable output electrical characteristics.
Industry Application
Application areas from the catalog.
Electrostatic suction
Catalog-listed application area for this static control product family.
Electrostatic dust removal
Catalog-listed application area for this static control product family.
Industrial material attraction or holding
Catalog-listed application area for this static control product family.
Other electrostatic generation applications
Catalog-listed application area for this static control product family.
Dimension Drawing
PDF catalog dimension drawing and technical tables.
